Meraki MR16 Access Point

Meraki MR16 Access PointEnlarge
Reviews
No reviews
Share
523.00 exc. VAT
627.60 inc. VAT
Select currency
GBP Euro US Dollar
Quantity

Be Notified


If you would like to be notified when the"Meraki MR16 Access Point" is re-stocked, please enter your contact details and we will notify you instantly.

Your Email Address
Your Name

Please Note: Confirmation of your "notify me" stock request will be emailed to the provided email address.
Available Product Options:
Please configure your product options below
Required MRXX License:
Require MRXX PoE Power Supply:
Require MRXX Mains Power Supply:

Availability: In Stock

Please note that this unit is a Cloud Based device. Licenses are required in order for this unit to operate. Please see the product options at the bottom of this page.

Meraki MR16 Access Point Dual-Radio 802.11n Access Point

The Meraki MR16 is an enterprise class, dual-concurrent 802.11n access point designed for high-density deployments in large offices, schools, hospitals, hotels and large retail stores.

The MR16 from Meraki features dual-concurrent, dual-band operation and advanced 802.11n technologies such as MIMO and beam forming, delivering the high throughput and reliable coverage required by the most demanding business applications like voice and video.

MR16 and the Meraki Cloud Controller: A Powerful Combo

The MR16 is managed through the Meraki Enterprise Cloud Controller, with an intuitive browser-based interface that lets you get up and running quickly without training or certifications.  Since the MR16 is self-configuring and managed over the web, you can even deploy the MR16 at a remote location without on-site IT staff.

The MR16 is monitored 24x7 from the Meraki Enterprise Cloud Controller which delivers real-time alerts if your network encounters problems.  Remote diagnostics tools enable real-time troubleshooting over the web, meaning multi-site, distributed networks can be managed remotely.

The MR16’s firmware is always kept up to date from the cloud.  New features, bug fixes, and enhancements are delivered seamlessly over the web, so you never have to manually download software updates or worry about missing security patches.

Technology

Technology
Description
Benefit
Traffic Shaper Application-aware bandwidth control See precisely how the network is being used, and reserve bandwidth for critical applications
Meraki NAC
Built-In Network Access Controll
Ensure that clients are protected from viruses; Enforce identity-based access control
Auto RF with
Spectrum Analysis
Automatic cloud-based RF optimization Automatically adapt to changing RF conditions to maximize overall network performance and capacity
Hybrid Cloud Architecture Tightly integrated hardware and Cloud hosted services system architecture High-performance and future proof networking with lower TCO and easier management
Centralized Management and Services Web-based multi-site management and testing tools Centrally manage branch or satellite offices without dedicated IT staff or multiple hardware controllers
Virtual Network Isolation Security policies and traffic separation for virtual wireless networks Multi-use networks requiring simultaneous guest access, prioritized voice and employee access
High-Performance Mesh Routing Scalable routing protocols and metrics for multi-radio mesh operation Wireless coverage in large areas where Ethernet cabling is unavailable
Priority Voice and PowerSave Support Advanced standards-compliant queuing and power management Enhanced call quality and battery life for wireless handsets

Product Highlights

  • Application-aware traffic shaping
  • Self-configuring, plug-and-play deployment
  • Sleek, low profile design blends into office environments
  • Optimized for voice and video
  • Dual-concurrent 802.11n radios, up to 600 Mbps throughput
  • Enhanced transmit power and receive sensitivity
  • Self-healing, zero-configuration mesh
  • Integrated enterprise security and guest access

Features

  • Dual enterprise class 802.11n radios, up to 600 mbit/sec
  • The MR16 features two powerful radios and advanced RF design for enhanced receive sensitivity.
  • Combined with 802.11n technologies including 2x2 MIMO and transmit beamforming, the MR16 delivers up to 600 mbit/sec throughput and up to 50% increased range compared to typical enterprise-class 802.11n access points, meaning fewer access points are required for a given deployment.
  • In addition, dual-concurrent 802.11n radios and band steering technology allow MR16 to automatically serve legacy 802.11b/g clients with the 2.4 Ghz radio and newer 802.11n clients to the 5 Ghz band to provide maximum speed to all clients.

Application-aware traffic shaping

The MR16 includes an integrated layer 7 packet inspection, classification, and control engine, enabling you to set QoS policies based on traffic type.  Prioritize your mission critical applications, while setting limits on recreational traffic, e.g. peer-to-peer and video streaming.

Automatic cloud-based RF optimization with spectrum analysis

The MR16’s sophisticated, automated RF optimization means that there is no need for the dedicated hardware and RF expertise typically required to tune a wireless network.

An integrated spectrum analyzer monitors the airspace for neighboring WiFi devices as well as non-802.11 interference – microwave ovens, Bluetooth headsets, etc.

The Meraki Cloud Controller then automatically optimizes the MR16’s channel selection, transmit power, and client connection settings, providing optimal performance even under challenging RF conditions.

Integrated enterprise security and guest access

The MR16 features integrated, easy-to-use security technologies to provide secure connectivity for employees and guests alike.  Advanced security features such as AES hardware-based encryption and WPA2-Enterprise authentication with 802.1x and Active Directory integration provide wire-like security while still being easy to configure.

One-click guest isolation provides secure, Internet-only access for visitors.  Our policy firewall (Identity Policy Manager) enables group-based, granular access policy control.

Voice and video optimized

The MR16 is highly optimized for to deliver reliable performance for latency-sensitive applications such as wireless voice and video, featuring Wireless Multi Media (WMM) support, 802.1p DSCP tagging and application-aware traffic shaping and QoS policies.

High performance mesh

The MR16’s advanced mesh technologies like multi-channel routing protocols and multiple gateway support enable scalable, high throughput coverage of hard-to-wire areas with zero configuration.

Mesh also improves network reliability - in the event of a switch or cable failure, the MR16 will automatically revert to mesh mode, providing continued gateway connectivity to clients.

Self-configuring, self-optimizing, self-healing

  • When plugged in, the MR16 automatically connects to the Meraki Enterprise Cloud Controller, downloads its configuration, and joins the appropriate network.
  • It self optimizes, determining the ideal channel, transmit power, and client connection parameters.  And it self heals, responding automatically to switch failures and other errors.

Low profile, environmentally friendly design

  • Despite its incredible power and feature set, the MR16 is the lowest profile 802.11n access point available - at just one inch thick, it blends seamlessly into any environment.
  • In addition to looking great, the MR16 is earth friendly: we’ve eliminated excess packaging and documentation, and 90% of the access point materials are recyclable.
  • A maximum power draw of only 10.5 watts and a cloud-hosted, multi-tenant controller mean that pollution, material utilization and your electric bill are kept to a minimum.
Product  MR12 MR16 MR24
Meraki Meraki MR12 Meraki MR16 Meraki MR24

Usage

Value-oriented WLAN Small branch, teleworker, home office Performance oriented WLAN Enterprise, campus, healthcare Highest performance, highest capacity WLAN High speed, and high density campus and enterprise

Radio specification

1 × 802.11b/g/n radio
300 Mbit/s max rate
2x2 MIMO, beamforming
2 × 802.11b/g/n radios
600 Mbit/sec max rate
2x2 MIMO, beamforming
2 × 802.11b/g/n radios
900 Mbit/sec max rate
3x3 MIMO with 3 streams, beamforming

Interface

1 × Gigabit and 1 × 10/100 Mbps Ethernet ports 1 × Gigabit Ethernet port 1 × Gigabit Ethernet port

Power

802.3af Power over Ethernet DC power adaptor 802.3af Power over Ethernet DC power adaptor 802.3af Power over Ethernet DC power adaptor

Physical design

Low-profile industrial design Wall and desktop mounting Low-profile industrial design Wall, desktop, and ceiling drop mounting (UL2043 Plenum rated) Low-profile industrial design Wall, desktop, and ceiling drop mounting (UL2043 Plenum rated)

Performance features

Priority Voice, Power Save (802.11e/WMM)
Enterprise-grade CPU
Hardware-accelerated encryption
Priority Voice, Power Save (802.11e/WMM)
Enterprise-grade CPU
Hardware-accelerated encryption
High-density support
Band steering
3-stream, 3x3 MIMO
Priority Voice, Power Save (802.11e/WMM)
Enterprise-grade CPU
Hardware-accelerated encryption
High-density support
Band steering

Mesh networking

Basic mesh High performance multi-radio mesh Very high performance multi-radio mesh

Note: Please refer to the Meraki Indoor Access Points Comparison Table for more information.

Meraki Indoor Access Points

Meraki MR16 Technical Specification

Radios

  • One 802.11b/g/n and one 802.11a/n radio
  • Dual concurrent operation in 2.4 and 5 GHz bands
  • Max throughput 600 Mbit/s

Operating Bands

FCC (US)

  • 2.412-2.484 GHz
  • 5.150-5.250 GHz (UNII-1)
  • 5.725 -5.825 GHz (UNII-3)

EU (Europe)

  • 2.412-2.484 GHz
  • 5.150-5.250 GHz (UNII-1)
  • 5.250-5.350, 5.470-5.725 GHz (UNII-2)

802.11n Capabilities

  • 2 x 2 multiple input, multiple output (MIMO) with two spatial streams
  • Maximal ratio combining (MRC)
  • Beamforming
  • 20 and 40 MHz channels
  • Packet aggregation
  • Cyclic shift diversity (CSD) support

Power

  • Power over Ethernet: 24 - 57 V (802.3af compatible)
  • 12V DC
  • Power consumption: 10.5 W max
  • Power over Ethernet injector and DC adapter sold separately

Mounting

  • All standard mounting hardware included
  • Desktop
  • Wall mount
  • Ceiling tile rail (9/16, 15/16 or 1 ½" flush or recessed rails)
  • Assorted cable junction boxes

Physical Security

  • Security screw included
  • Kensington lock hard point
  • Anti-tamper cable bay
  • Concealed mount plate

Environment

  • Operating temperature: 32 °F to 104 °F (0 °C to 40 °C)
  • Humidity: 5 to 95% non-condensing

Physical Dimensions

  • 7.3” x 5.8” x 1.0” (185 mm x 147 mm x 25 mm) not including desk- mount feet or mount plate
  • Weight: 17 oz (0.48 kg)

Antenna

  • Integrated omni-directional antennas
  • Gain: 3 dBi @ 2.4 GHz, 5 dBi @ 5 GHz

Interfaces

  • 1 × 100/1000Base-T Ethernet (RJ45) with 48V DC 802.3af PoE
  • 1 × DC power connector (5mm x 2.1mm, center positive)

Security

  • Integrated policy firewall (Identity Policy Manager)
  • 24 × 7 Wireless Intrusion Detection
  • Guest Isolation
  • WEP, WPA
  • WPA2-PSK
  • WPA2-Enterprise with 802.1X
  • TKIP and AES encryption
  • VLAN tagging (802.1Q)

Quality of Service

  • Wireless Quality of Service (WMM/802.11e)
  • Advanced Power Save (U-APSD)
  • DSCP (802.1p)

LED Indicators

  • 4 signal strength
  • 1 Ethernet connectivity
  • 1 power/booting/firmware upgrade status

Regulatory

  • FCC (US)
  • IC (Canada)
  • CE (Europe)
  • IEC / EN60950-1
  • UL2043 (Plenum rating)
  • RoHS

Certification

  • Wi-Fi Alliance

Warranty

  • Lifetime hardware warranty with advanced replacement included

Note: Please refer to the Meraki Indoor Access Points Comparison Table for more information.
