Ubiquiti UniFi Switch 8 Port - US-8 (Non-PoE)

55 Based on 1 ratings.
85.00 exc. VAT
102.00 inc. VAT
Availability:In stock for next day delivery
Reseller discounts available
Qty:
Key Features
  • Switching Capacity: 16 Gbps
  • Forwarding Rate: 11.9 Mpps
  • 8 x Gigabit RJ45 Ports

Pricing Volume Price Discounts

No volume pricing discounts available

Shipping Shipping Options

Shipping costs are calculated based on weight and destination during checkout. For next day delivery our cut off is 16:00.

Support Product install/setup

Want help installing this product? Add premium support to your order.

Downloads Documents & Manuals

SKU:US-8
Available Product Options:
UK Power Cable (free of charge):

Ubiquiti UniFi Switch 8 Port - US-8 (Non-PoE)

The Ubiquiti UniFi Switch 8 is a non-PoE 8 port gigabit switch, which supports PoE passthrough. It is perfect for cleanly adding Ethernet ports where needed, all in a compact form factor. Alike the other UniFi Switches, the US-8 is fully manageable, delivering robust performance for your network.

Ubiquiti UniFi Switch 8 Port (Non-PoE) Key Features

  • (8) Gigabit RJ45 Ports
  • (1) PoE Passthrough Port
  • Non-Blocking Throughput: 8 Gbps
  • Switching Capacity: 16 Gbps
  • Forwarding Rate: 11.9 Mpps
  • Maximum Power Consumption: 12W
  • PoE or DC Input Option

Non-Blocking Throughput
The US-8 features 8 Gigabit Ethernet ports in a compact form factor. For its total, non-blocking throughput, each UniFi Switch supports up to 8 Gbps.

Switching Capacity
The UniFi US-8 offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss, with a switching capacity of 16 Gbps.


Seamless Integration
A single instance of the UniFi Controller running in the cloud can manage multiple UniFi sites within a centralised interface. Each site is logically separated and has its own network monitoring, configuration, maps, statistics, and admin accounts.


Ubiquiti UniFi Switch 8 Port (Non-PoE) - Technical Specifications

General

  • Dimensions 148.0 x 99.5 x 30.7 mm (5.83 x 3.92 x 1.21")
  • Weight 432 g (15.24 oz)
  • Enclosure Characteristics SGCC Steel
  • Total Non-Blocking Throughput 8 Gbps
  • Switching Capacity 16 Gbps
  • Forwarding Rate 11.9 Mpps
  • Max. Power Consumption 12W (Excluding PoE Output)
  • Max. Passive PoE Wattage per Port PoE Mode 1: 12W @ 802.3at
  • PoE Mode 2: 12W @ 48V
  • PoE Mode 3: 12W @ 24V
  • DC Input Mode: 12W @ 48V or 12W @ 24V
  • Passive PoE Voltage Range Depends on Power Source
  • Power Method (1) DC 48V or 24V, Max. 1.25A
  • (1) PoE Input, 802.3 af/at (Pins +1, 2; -3, 6); Passive 24V (Pins +4, 5; -7, 8)
  • Supported Voltage Range DC: 48V or 24V; 48V Mode: 56V to 40V; 24V Mode: 27V to 20V
  • Power Supply External AC/DC Adapter, 48V, 0.5A
  • LEDs PoE (Port 8), Speed/Link/Activity (All Ports)
  • Networking Interfaces (8) 10/100/1000 Mbps RJ45 Ports
  • PoE In Interface (Port 1) PoE Mode 1: 802.3af/at (Pins +1, 2; -3, 6)
  • PoE Mode 2: Passive 24V or 48V (2-Pair Pins +4, 5; -7, 8)
  • PoE Mode 3: Passive 24V; (4-Pair Pins +1, 2; -3, 6 and +4, 5; -7, 8)
  • PoE Out Interface (Port 8) PoE Mode 1: 48V (Pins +1, 2; -3, 6)
    PoE Mode 2: Passive 24V or 48V
    (2-Pair Pins +4, 5; -7, 8)
    PoE Mode 3: Passive 24V
    (4-Pair Pins +1, 2; -3, 6 and +4, 5; -7, 8)
    DC Input Mode: DC Passthrough
    (Pins +1, 2; -3, 6)
  • Management Interface Ethernet In-Band Management
  • ESD/EMP Protection Air: ± 24 kV, Contact: ± 24 kV
  • Operating Temperature -5 to 45° C (23 to 113° F)
  • Operating Humidity 5 to 95% Noncondensing

Specifications Tab

by Graham Brown These switches have proven to be rock solid thus far, basic management is easy, VLANs can be set up .. See full review TEXT_OF_5_STARS Date Added: Tuesday 27 February, 2018

Displaying 1 to 1 (of 1 reviews)
