Ubiquiti EdgePower 24V Power Supply with UPS and PoE (EP-24V-72W)

0 Based on 0 ratings.
22/12/2019 £132.60 exc. VAT
159.12 inc. VAT
Availability:Discontinued Coming Soon
Apply for Trade Pricing
Qty:
Key Features
  • Reliable and Convenient UPS for WISPs
  • UNMS™ Remote Management
  • Automatic Alerts for Power Outages

Pricing Volume Price Discounts

No volume pricing discounts available

Shipping Shipping Options

Shipping costs are calculated based on weight and destination during checkout. For next day delivery our cut off is 16:00.

Support Product install/setup

Want help installing this product? Add premium support to your order.

Downloads Documents & Manuals

SKU:EP-24V-72W
Available Product Options:
Need Product Setup / Training / Support?:
  • Product Details
  • Reviews
  • White Papers / Case Studies

Ubiquiti EdgePower 24V Power Supply with UPS and PoE (EP-24V-72W)

The Ubiquiti EdgePower 24V is a convenient UPS device with dual PoE output ports to protect your WISP site against power loss.

Ubiquiti EdgePower 24V Key Features

  • Reliable and Convenient UPS for WISPs
  • UNMS™ Remote Management
  • Automatic Alerts for Power Outages

You can receive alerts in the event of a power outage, and the EP-24V-72W offers a 12V lead acid battery input for redundancy if the AC input fails over (battery not included). The EP-24V-72W offers the following outputs: 24VDC and 2 x 24V passive PoE.

In the following diagram, the EP-24V-72W powers both the EdgeRouter™ ER-12, which acts as an internet gateway, and the EdgeSwitch ES-10XP, which acts as a PoE switch for the LAN. The EdgePower is also connected to the EdgeSwitch via an Ethernet cable for management.

Example

Versatile Design

The rack-mountable EdgePower 24V features 24VDC and 2 RJ45 PoE Ports.

Versatile Design

UPS for WISP

You can receive alerts in the event of a power outage, and the EdgePower 24V offers a 12V lead acid battery input for redundancy if the AC input fails over (battery not included).

UPS for WISP

Ubiquiti EdgePower 24V Technical Specifications

General

  • Dimensions: 192 x 43.7 x 115 mm (7.559 x 1.72 x 4.528")
  • Weight: 650 g (1.43 lb)

Interfaces

  • Networking: 2 x 10/100 Mbps RJ45 Ports
  • Management: Ethernet In-Band

PoE Output:

  • 2 x 24VDC Passive PoE (Pins 4, 5+; 7, 8-)

DC Output

  • 24V, 3A

Power Supply

  • AC Input: AC/DC 72W
  • Battery Input: 12VDC Lead Acid Battery (Battery not included)

Max. Power Consumption

  • System: 2W
  • Output: 72W

LEDs

  • System: Status
  • RJ45 Data Ports: PoE; Link/ Activity

ESD/ EMP Protection

  • Air: ± 12 kV, Contact: ± 12 kV

Operating Temperature

  • 0 to 40° C (32 to 104° F)

Operating Humidity

  • 10 to 90% Noncondensing

Certifications

  • CE
  • FCC
  • IC
