Overview

•  Dimensions:  442 x 480 x 44 mm (17.4 x 18.9 x 1.7")
•  Port Layout:  2.5 GbE RJ45 - 16 (2.5G/1G/100M/10M) 10 GbE RJ45 - 32 (10G/5G/2.5G/1G/100M/10M) 25G SFP28 - 4 (25G/10G/1G)

Performance

•  Switching Capacity:  920 Gbps
•  Total Non-Blocking Throughput: 460 Gbps
•  Forwarding Rate: 684 Mpps
•  Supported VLANs:1000
•  MAC Address Table Size: 128,000
•  L3 Table Size ARP Entries   128,000
  IPv4 Routes   256,000
•  Packet Buffer Size: 8 MB
• Access Lists:
  IPv4 - 256
  MAC - 256

Layer 3 Features

•  DHCP Server (Local Networks):  Yes
•  DHCP Relay:  Yes
•  Inter-VLAN Routing (Local Networks):  Yes
•  Static Routing (Local Networks):  Yes

Layer 2 Features

•  LACP Port Aggregation:  Yes
•  STP & RSTP: Yes
•  Advanced IGMP Configuration (Querier, Fast Leave, Router Port): Yes
•  IGMP Snooping:  Yes
•  802.1X Control:  Yes
•  MAC-Based ACLs & Device Isolation:  Yes
•  DHCP Snooping & Guarding:  Yes
•  Egress Rate Limit:  Yes
•  Flow Control:  Yes
•  Storm Control:  Yes
•  Multicast & Broadcast Rate Limiting: Yes
•  MAC Address Blocking:  Yes
•  IP-Based ACLs & Network Isolation:  Yes
•  MAC-Based Port Restriction:  Yes
•  Port Isolation:  Yes
•  Port Mirroring:  Yes
•  Jumbo Frames:  Yes
•  LLDP-MED:  Yes
•  Voice VLAN:  Yes
•  Loop Protection:  Yes

Hardware

•   Max. Power Consumption: 250W
•  Power Method:  (1) Universal input, 100—240V AC, 50/60 Hz, (1) USP-RPS DC input
•  Power Input Method:  AC input
•  Power Supply:  AC/DC, internal, 300W
•  Supported Voltage Range:  100—240V AC
•  Management:  Etherne,  AR
•  Weight : Without mounting brackets: 7.5 kg (16.5 lb) With mounting brackets: 7.6 kg (16.8 lb)
•  Enclosure Material:  SGCC steel
•  Mount Material: SGCC steel
•  Supported Rack Depth:  482.6 mm (19") four-post racks Posts depths ranging from 600 to 1,066 mm (23.6-42”)
•  LCM Display:  1.3" touchscreen
•  ESD/EMP Protection: Air: ± 30kV, contact: ± 20kV
•  Ambient Operating Temperature:  -5 to 40° C (23 to 104° F)
•  Ambient Operating Humidity:  10 to 90% noncondensing
•  Certifications:  CE, FCC, IC
•  Etherlighting:
  Ethernet: Yes
  SFP+: Yes
•  LEDs
  RPS: Yes
•  NDAA Compliant: Yes
