Ubiquiti UniFi Switch Pro XG Aggregation(USW-Pro-XG-Aggregation)

0 Based on 0 ratings.
Write a Review
SKU:USW-Pro-XG-Aggregation
Enquire
Coming Soon
Accessories, Add-Ons, and Extras

Need Trade Pricing?

If you are a Wireless or comms reseller and are interested in selling 4Gon products as part of your business offering, you can apply to become an authorised reseller. Once accepted, you will have access to reseller pricing. Apply now

Documents and Manuals

No documents available for download

Key Features
  • 32 × 25G SFP28 ports
  • 1.6 Tbps switching capacity
  • 1.3" Touchscreen with AR switch management
  • Product Details
  • Reviews
Please Note: If you are looking for storage for your data equipment, please see our selection of Allrack Cabinets.

Ubiquiti UniFi Switch Pro XG Aggregation(USW-Pro-XG-Aggregation)

The Ubiquiti UniFi Switch Pro XG Aggregation is a managed Layer 2 switch, is equipped with eight 10G SFP+ ports to facilitate link aggregation, providing enhanced capacity and improved availability. With its Layer 2 capabilities and support for high-bandwidth links, USW-Aggregation is well-suited for aggregation switching in UniFi solutions that employ diverse interconnect topologies.

Ubiquiti UniFi Switch Pro XG Aggregation Key Features

  • Ports: 32 × 25G SFP28 ports
  • Switching Capacity: 1.6 Tbps
  • Forwarding Rate: 1,190 Mpps
  • Performance Features: Non-blocking throughput, Ultra-low latency ideal for high-bandwidth aggregation
  • Layer 3 Capabilities: Inter-VLAN routing, Static routing, DHCP server and relay
Ubiquiti UniFi Switch Pro XG Aggregation Technical Specification

Overview

  • Dimensions: 442.4 x 43.7 x 480 mm (17.4 x 1.7 x 18.9")
  • Port Layout - 25G SFP28 32 (25G/10G/1G)
  • Redundancy: DC Power Backup
  • Layer 3 - Yes
  • Form Factor - Rack Mount (1U)
  • Etherlighting™ - Yes

Performance

  • Switching Capacity: 1.6 Tbps
  • Total Non-Blocking Throughput: 800 Gbps
  • Forwarding Rate: 1.2 Bpps
  • Supported VLANs: 1,000
  • MAC Address Table Size: 32,000
  • L3 Table Size:
    • ARP Entries - 128,000
    • IPv4 Routes - 256,000
  • Packet Buffer Size: 8 MB

Layer 3 Features

  • DHCP Server (Local Networks): Yes
  • DHCP Relay: Yes
  • Inter-VLAN Routing (Local Networks): Yes
  • Static Routing (Local Networks): Yes

Layer 2 Features

  • LACP Port Aggregation: Yes
  • STP & RSTP: Yes
  • Advanced IGMP Configuration (Querier, Fast Leave, Router Port): Yes
  • IGMP Snooping: Yes
  • 802.1X Control: Yes
  • MAC-Based ACLs & Device Isolation: Yes
  • DHCP Snooping & Guarding: Yes
  • Egress Rate Limit: Yes
  • Flow Control: Yes
  • Storm Control: Yes
  • Multicast & Broadcast Rate Limiting: Yes
  • MAC Address Blocking: Yes
  • IP-Based ACLs & Network Isolation: Yes
  • MAC-Based Port Restriction: Yes
  • Port Isolation: Yes
  • Port Mirroring: Yes
  • Jumbo Frames: Yes
  • LLDP-MED: Yes
  • Voice VLAN: Yes
  • Loop Protection: Yes

Hardware

  • Max. Power Consumption:200W
  • Power Method: (1) Universal input, 100—240V AC, 50/60 Hz, (1) USP RPS DC input
  • Power Input Method: AC input
  • Power Supply: AC/DC, internal, 200W
  • Supported Voltage Range: 100—240V AC
  • Management: Ethernet, AR
  • Weight: 7 kg (19.8 lb)
  • Enclosure Material: SGCC steel
  • Mount Material: SGCC steel
  • Supported Rack Depth: 482.6 mm (19") four-post racks. Posts depths ranging from 600 to 1,066 mm (23.6-42”)
  • LCM Display: 1.3" touchscreen
  • ESD/EMP Protection: Air: ± 12kV, contact: ± 8kV
  • Ambient Operating Temperature: -5 to 40° C (23 to 104° F)
  • Ambient Operating Humidity: 10 to 90% noncondensing
  • Etherlighting™:
    • SFP28 - Yes
  • LEDs: RPS - Yes
  • Certifications: CE, FCC, IC
  • NDAA Compliant: Yes
