Ubiquiti UniFi Switch 16 XG - 10G 16-Port Managed Switch

0 Based on 0 ratings.
19/08/2020 £430.50 exc. VAT
516.60 inc. VAT
Availability:In stock for next day delivery
Apply for Trade Pricing
Qty:
Key Features
  • 12 x 1G/10G SFP+ Ports
  • 4 x 1G/10G RJ45 Ports
  • 1 x RJ45 Serial Console Port

Pricing Volume Price Discounts

No volume pricing discounts available

Shipping Shipping Options

Shipping costs are calculated based on weight and destination during checkout. For next day delivery our cut off is 16:00.

Support Product install/setup

Want help installing this product? Add premium support to your order.

Downloads Documents & Manuals

SKU:US-16-XG
Available Product Options:
UK Power Cable (free of charge):
Wall mount cabinet required?:
Floor standing cabinet required?:
Shelf for floor standing cabinet required?:
Need Product Setup / Training / Support?:
  • Product Details
  • Reviews
  • White Papers / Case Studies
Please Note: If you need a storage cabinet for this product, please select from the Available Product Options above. See All-Rack for full details.

Ubiquiti UniFi Switch 16 XG - 10G 16-Port Managed Switch

Part of the UniFi range, the Ubiquiti US-16-XG is a 16 port 10Gb switch, boasting a huge non-blocking throughput of 160Gbps. The US-16-XG is also equipped with 12 10Gb SFP+ ports, alongside 4 10Gb RJ45 ports for flexible connectivity.

Ubiquiti UniFi Switch 16 XG Features

  • (12) 1G/10G SFP+ Ports
  • (4) 1G/10G RJ45 Ports
  • (1) RJ45 Serial Console Port
  • Non-Blocking Throughput: 160 Gbps
  • Switching Capacity: 320 Gbps
  • Forwarding Rate: 238.10 Mpps
  • Rack Mountable with Mount Brackets (Included)
  • DC Input Option (Redundant or Stand-Alone)

10G Aggregation Switch for Enterprise Networks
Build and expand your network with Ubiquiti Networks® UniFi® Switch 16 XG, part of the UniFi Enterprise System. The US-16-XG is a fully managed, 16 port, 10G fiber switch that enhances network capacity by providing high-bandwidth aggregation connectivity to multiple switches in your network. The US-16-XG offers an extensive suite of advanced Layer-2 switching features and protocols.
10G Aggregation Switch for Enterprise Networks

Multi-Site Management
A single instance of the UniFi Controller running in the cloud can manage multiple UniFi sites within a centralised interface. Each site is logically separated and has its own network monitoring, configuration, maps, statistics, and admin accounts.
Multi-Site Management


10G High-Capacity Links
The US-16-XG offers maximum performance and low latency as an aggregation switch. For fiber connectivity, it features 12 SFP+ ports. For CAT 6/5e cable connectivity, the US-16-XG offers four 10G RJ45 ports.
10G High-Capacity Links

Seamless Integration
The UniFi® Switch integrates seamlessly into the UniFi Software-Defined Networking (SDN) platform to create a highly scalable, end-to-end system of network devices across multiple locations - all controlled from a single interface.


              Seamless Integration
                     Deployment

Ubiquiti UniFi Switch 16 XG - Technical Specifications

General

  • Dimensions: 443 x 221 x 43 mm (17.44 x 8.70 x 1.69")
  • Weight:
    - Without Mount Brackets: 2.62 kg (5.78 lb)
    - With Mount Brackets: 2.71 kg (5.97 lb)
  • Enclosure Characteristics: SGCC Steel
  • Total Non-Blocking Throughput: 160 Gbps
  • Switching Capacity: 320 Gbps
  • Forwarding Rate: 238.10 Mpps
  • Max. DC Power Consumption 36W (Excludes SFP/SFP+ Modules)
  • Power Method:
    - AC: 100-240VAC/50-60 Hz, Universal Input
    - DC: DC 56W, 57 to 20V, with 48/24VDC Terminal Block
  • Supported Voltage Range:
    - 100 to 240VAC
    - 57 to 20VDC
  • Power Supply: AC/DC, Internal, 56W DC
  • LEDs Per Data Port: Speed/Link/Activity
  • Sound Level (Background noise level: 27.5 dBa):
    - Fan Level 0: 1.0 dBr
    - Fan Level 1: 10.7 dBr
    - Fan Level 2: 12.2 dBr
    - Fan Level 3: 12.8 dBr
  • Networking Interfaces:
    - (12) 1/10 Gbps SFP+ Ethernet Ports
    - (4) 1/10 Gbps RJ45 Ethernet Ports
  • Management Interface: (1) RJ45 Serial Port Out-of-Band, Ethernet Ports In-Band
  • Certifications: CE, FCC, IC
  • Rack Mount: Yes, 1U High
  • ESD/EMP Protection: Air: ± 24 kV, Contact: ± 24 kV
  • Operating Temperature: -5 to 40° C (23 to 104° F)
  • Operating Humidity: 5 to 95% Noncondensing
  • Shock and Vibration: ETSI300-019-1.4 Standard
