Ubiquiti UniFi Switch 24 US-24 (NON-POE)

44 Based on 1 ratings.
03/03/2020 £156.00 exc. VAT
187.20 inc. VAT
Availability:In stock for next day delivery
Apply for Trade Pricing
Key Features
  • 24 x Gigabit RJ45 Ports
  • Switching Capacity: 52 Gbps
  • Forwarding Rate: 38.69 Mpps

Pricing Volume Price Discounts

No volume pricing discounts available

Shipping Shipping Options

Shipping costs are calculated based on weight and destination during checkout. For next day delivery our cut off is 16:00.

Support Product install/setup

Want help installing this product? Add premium support to your order.

Downloads Documents & Manuals

Available Product Options:
UK Power Cable (free of charge):
Wall mount cabinet required?:
Floor standing cabinet required?:
Shelf for floor standing cabinet required?:
Need Product Setup / Training / Support?:
  • Product Details
  • Reviews
  • White Papers / Case Studies
Please Note: If you need a storage cabinet for this product, please select from the Available Product Options above. See All-Rack for full details.

Ubiquiti UniFi Switch 24 US-24 (NON-POE)

The Ubiquiti UniFi US-24 (NON-POE) is a fully managed twenty-four port switch that delivers robust performance, intelligent switching for growing networks. The Ubiquiti UniFi US-24 delivers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.

Ubiquiti UniFi US-24 Key Features

  • 24 Gigabit RJ45 Ports
  • 1 standard SFP port, 1 Serial Console Port
  • Non-Blocking Throughput: 26 Gbps
  • Switching Capacity: 52 Gbps
  • Forwarding Rate: 38.69 Mpps
  • Maximum Power Consumption: 25W

Switching Performance
The Ubiquiti US-24 offers the forwarding capacity to simultaneously process traffic on all ports at line rate withoutany packet loss. For its total, non‑blocking throughput, the 24‑port model supports up to 26 Gbps.

Convenient PoE+ Support
Featuring auto-sensing IEEE 802.3af/at PoE, the Ubiquiti US-24 is able to power multiple devices on the network.

Seamless Integration
The UniFi US-24 switch integrates seamlessly into the UniFi Software-Defined Networking (SDN) platform to create a highly scalable, end-to-end system of network devices across multiple locations — all controlled from a single interface.


Ubiquiti UniFi US-24 (NON-POE) - Technical Specifications


  • Dimensions: 443 x 43 x 221 mm (17.44 x 1.69 x 8.70")
  • Weight:
    Rack-Mount Brackets Excluded - 2.51 kg (5.53 lb)
    Rack-Mount Brackets Included - 2.60 kg (5.70 lb)
  • Networking Interfaces:
    (24) 10/100/1000 Mbps RJ45 Ethernet Ports
    (1) 1 Gbps SFP Ethernet Ports
  • Management Interface: (1) RJ45 Serial Port Out-of-Band, Ethernet In-Band
  • Total Non-Blocking Throughput: 26 Gbps
  • Switching Capacity: 52 Gbps
  • Forwarding Rate: 38.69 Mpps
  • Power Method: 100-240VAC/50-60 Hz, Universal Input
  • Power Supply: AC/DC, Internal, 25W DC
  • Max. Power Consumption: 25W
  • LEDs per Port: Speed/Link/Activity
  • Sound Level:
    Fan Level: 0 - 34 dBa
    Fan Level: 1 - 37 dBa
  • ESD/EMP Protection: Air: ± 24 kV, Contact: ± 24 kV
  • Rack Moun:t Yes, 1U High
  • Shock and Vibration: ETSI300-019-1.4 Standard
  • Operating Temperature: -5 to 40° C (23 to 104° F)
  • Operating Humidity: 5 to 95% Noncondensing
  • Certifications: CE, FCC, IC
